UL498 Figure 69.1 Reference Plug

उत्पाद विवरण:

Place of Origin: China
ब्रांड नाम: Kingpo
प्रमाणन: Calibration Certificate

भुगतान & नौवहन नियमों:

Minimum Order Quantity: 1
मूल्य: To be quoted
पैकेजिंग विवरण: सुरक्षा दफ़्ती पैक या प्लाईवुड बॉक्स
Delivery Time: 15 work days
Payment Terms: T/T
अब से संपर्क करें

विस्तार जानकारी

Place of origin: Guangdong,China(mainland) Standard: American Standard UL498
हाई लाइट:

electrical socket tester

,

कठोरता परीक्षण उपकरण

उत्पाद विवरण



UL498 Figure 69.1 Reference Plug



American Standard UL498 plug and socket gauge
  Gauge drawing number standard number number name
1 Articulate probe with web stop Figure 9.1 UL 498 1
2 Probe figure 10.1 UL 498 1
3 Flat probe figure 31.1 UL 498 1
4 Reference plug
5 the simulation of plug tension device should a figure figure 69.1 UL 498 1 sets
6 Improper insertion test blades figure 94.1 UL 498 2
7 Test plug figure 105.1 UL 498 2
8 Test blade figure 105.2 UL 498 1
9 Receptacle test fixture figure 118.1 UL 498 1
10 Push out tool figure 118.3 UL 498 1
11 Bridge figure 118.5 UL 498 1
12 Test pin A figure 119.1 UL 498 1
13 Test pin B figure 119.2 UL 498 1
14 57g ground pin figure 119.3 UL 498 1
15 113g ground pin figure 119.4 UL 498 1
16 No.14AWG test pin figure 129.2 UL 498 1
17 Test probe figure 132.1 UL 498 1
18 Fixture for assembly security test figure 144.2 UL 498 1
19 Over size ground pin figure SD 13.2 UL 498 1
