Voc Testing Equipment , Micro VOC Release Chamber Positive Pressure
उत्पाद विवरण:
| Place of Origin: | China |
| ब्रांड नाम: | KingPo |
| प्रमाणन: | Calibration Certificate |
भुगतान & नौवहन नियमों:
| Minimum Order Quantity: | 1 |
|---|---|
| मूल्य: | To be quoted |
| पैकेजिंग विवरण: | सुरक्षा दफ़्ती पैक या प्लाईवुड बॉक्स |
| प्रसव के समय: | 35 दिन काम |
| Payment Terms: | T/T |
| आपूर्ति की क्षमता: | प्रति माह 3 सेट |
|
विस्तार जानकारी |
|||
| जलवायु कक्ष का आयतन: | Φ64*H34mm=116ml, इनर आर्क सरफेस चैम्बर | तापमान की समायोज्य रेंज: | 5% आरएच (65 ℃) |
|---|---|---|---|
| दबाव: | सकारात्मक दबाव | वायु विनिमय दर: | 10~500/बार ± 5% |
| हवा का वेग: | 10 ~ 500 एमएल / मिनट (गुणवत्ता प्रवाह नियंत्रक) | ||
| हाई लाइट: | ozone test chamber,जलवायु परीक्षण के चैम्बर |
||
उत्पाद विवरण
Micro VOC Release Chamber
Product purpose
• To detect substance released on the material surface in steady temperature.First,data of volatile substances and molecular materials before modification;Second,comparison of product properties(such as different colors or patterns)within the effective range;Third,detection of sample machine and low volatile materials;fourth,detection of the consensus of products during official authentication test.
• Measure volatile and semivolatile organic compounds in major materials,and implement regular quality control.
• Detect volume and radiations.
• When temperature changes,detect the steam permeated into materials
• Analysis of flavors and fragrances
Function
Micro sampling chamber can provide standard testing environment(temperature,cleanliness,relative humidity,air exchange rate,,etc) and detect VOC/SVOC and water content of various materials and products.It is very suitable for concrete analysis of heterogeneous prototype and detection of low trace elements.
Reference Standard
ISO 12219-3: 2012(E) air in road vehicles Section 3 Determination method for screening release emission of volatile organic components of materials of vehicle interiors with micro test chamber method.
Technical Parameters:
| Product Model※1 | MV-4 | MV-6 | MV-8 |
| Environmental temperature | 5~35℃ | ||
| Environmental humidity | ≤90%R.H | ||
| Requirements for Environmental | Cleanliness No pollutant source in the surrounding environment TVOC 500μg/m³ | ||
| Volume of climate chamber | Φ64*H34mm=116ml,inner arc surface chamber | ||
| Quantity of inner tanks※1 | Serveral,with aspiration at the bottom ring and outlet and sampling at the ceiling | ||
| Adjustable range of temperature | 60~200℃high temperature cleaning more than 260℃ | ||
| Adjustable range of humidity(optional) | 5%R.H(65℃) | ||
| Pressure | Positive pressure | ||
| Temperature fluctuation | ±0.3℃(fluctuation) | ||
| Temperature deviation | ±1.0℃(deviation) | ||
| Humidity fluctuation※2(optional) | ±2.5%R.H | ||
| Humidity deviation※2(optional) | ±3% | ||
| Air exchange rate | 10~500/times±5% | ||
| Air velocity | 10~500mL/min(quality flow controller) | ||
| Power | Alternating current 220V/50Hz | ||
| Starting power※3 | 3kw | ||
| Operating power※3 | 1.5kw | ||
| External dimension of climate chamber※4 | W580mm*D890*H1050(when there are 6 inner tanke),it is up to the quantity of inner tanks | ||
| Background concentration of methanol | smaller than 15μg/m³,the lowest 6μg/m³ | ||
| Background concentration of VOC | single VOC has a concentration smaller than 2 μg/m³,T VOC 20 μg m dust filtrated TVOC has a concentration smaller than 20μg/m³ | ||
| Rate of recovery | Formaldehyde,octanol,4 phenyl cyclohexene,dodecane and tetradecane have a recovery rate larger than 80% | ||
| Clean air system | pressure＞1.0Mpa,dry and clean gases(non combustible and noe toxic harmful gases such as air,nitrogen and argon) | ||
| Cooling mode | Air cooling | ||
| Controller | Color touch screen man-machine interface;Mitsubishi pld controller | ||
Note:
※ 1 Type:MV-6,MV presents micro VOC chamber and figure 6 presents quantity of inner tanks.Quantity of inner tanks and divided into 4,6,8.
※ 2 The function exists when there is only requirement for humidity.
※ 3 This data occurs when there are 6 inner tanks and it changes with quantity of inner tanks
※ 4 This data occurs when there are 6 inner tanks and it changes with quantity of inner tanks
